70BYJ 减速永磁步进电动机
典型应用场景：监控云台，麻将机，过胶机，投幕机，阀门控制，广告灯箱，自动烧烤炉
重量：850g
|
型号
|
电压
|
相数
|
相电阻
|
驱动方式
|
步距角
|
减速比
|
起动频率
|
运行转矩
|
绝缘耐压
|
绝缘等级
|
|
Model
|
Voltage
(V)DC
|
Phase
|
Resistance/phase
(Ω)
|
Drive Method
|
Step Angle
（Deg）
|
Speed Ratio
|
Pull in Rates（PPS）
|
Pull out Torque (g.cm)
|
Dielectric Stength
|
Class of insulation
|
|
70BYJ28-30-150J
|
24
|
2
|
30
|
2-1-2 Bipolar
|
5.625/150
|
1:150
|
350
|
100
|
500V AC 1Min
|
E
|
|
70BYJ28-30-75J
|
24
|
2
|
30
|
2-1-2 Bipolar
|
5.625/75
|
1:75
|
350
|
60
|
500V AC 1Min
|
E
|
|
70BYJ28-30-37J
|
24
|
2
|
30
|
2-1-2 Bipolar
|
5.625/37.5
|
1:37.5
|
350
|
40
|
500V AC 1Min
|
E
|
|
70BYJ28-30-25J
|
24
|
2
|
30
|
2-1-2 Bipolar
|
5.625/25
|
1:25
|
350
|
30
|
500V AC 1Min
|
E
|
|
70BYJZ28-30-18J
|
24
|
2
|
30
|
2-1-2 Bipolar
|
5.625/18.75
|
1:18.75
|
350
|
25
|
500V AC 1Min
|
E
|
|
70BYJ28-30-150J
|
24
|
2
|
30
|
2-1-2 Bipolar
|
5.625/15
|
1:15
|
350
|
20
|
500V AC 1Min
|
E
|
|
70BYJ28-30-75J
|
24
|
2
|
30
|
2-1-2 Bipolar
|
5.625/12.5
|
1:12.5
|
350
|
18
|
500V AC 1Min
|
E
|
|
70BYJ28-30-37J
|
24
|
2
|
30
|
2-1-2 Bipolar
|
5.625/9.375
|
1:9.375
|
350
|
12
|
500V AC 1Min
|
E
|
|
70BYJ28-30-25J
|
24
|
2
|
30
|
2-1-2 Bipolar
|
5.625/7.5
|
1:7.5
|
350
|
8
|
500V AC 1Min
|
E
|
|
70BYJ28-30-18J
|
24
|
2
|
30
|
2-1-2 Bipolar
|
5.625/6.25
|
1:6.25
|
350
|
6
|
500V AC 1Min
|
E
|
|
|
