35BYJHP 减速永磁步进电动机
典型应用场景：空调风门调节，小型云台，安防监控器，智能洁具，投影仪镜头调节，发电机节气门，自动门锁
重量：90g
|
型号
|
电压
|
相数
|
相电阻
|
驱动方式
|
步距角
|
减速比
|
起动频率
|
运行转矩
|
绝缘耐压
|
绝缘等级
|
|
Model
|
Voltage
(V)DC
|
Phase
|
Resistance/phase
(Ω)
|
Drive Method
|
Step Angle
（Deg）
|
Speed Ratio
|
Pull in Rates（PPS）
|
Pull out Torque (g.cm)
|
Dielectric Stength
|
Class of insulation
|
|
35BYJ212HP-10-24J
|
12
|
2
|
10
|
2-1-2 Bipolar
|
3.75/24
|
1:24
|
600
|
500
|
500V AC 1Min
|
E
|
|
35BYJ212HP-60-42J
|
12
|
2
|
60
|
2-1-2 Bipolar
|
3.75/42.5
|
1:42.5
|
600
|
800
|
500V AC 1Min
|
E
|
|
35BYJ212HP-50-80J
|
12
|
2
|
50
|
2-1-2 Bipolar
|
3.75/80
|
1:80
|
600
|
2000
|
500V AC 1Min
|
E
|
|
35BYJ412HP-30-12J
|
12
|
4
|
30
|
4-1-2 Unipolar
|
3.75/12
|
1:12
|
600
|
2500
|
500V AC 1Min
|
E
|
|
35BYJ412HP-40-42J
|
12
|
4
|
40
|
4-1-2 Unipolar
|
3.75/42.5
|
1:42.5
|
600
|
2500
|
500V AC 1Min
|
E
|
|
35BYJ412HP-60-80J
|
12
|
4
|
60
|
4-1-2 Unipolar
|
3.75/80
|
1:80
|
600
|
2500
|
500V AC 1Min
|
E
|
|
35BYJ412HP-100-42J
|
12
|
4
|
100
|
4-1-2 Unipolar
|
3.75/42.5
|
1:42.5
|
600
|
2500
|
500V AC 1Min
|
E
|
|
35BYJ26HP-60-80J
|
12
|
2
|
60
|
2-1-2 Bipolar
|
7.5/80
|
1:80
|
600
|
2000
|
500V AC 1Min
|
E
|
|
35BYJ46HP-100-42J
|
12
|
4
|
100
|
4-1-2 Unipolar
|
7.5/42.5
|
1:42.5
|
600
|
1200
|
500V AC 1Min
|
E
|
|
|
