35BYJH 减速永磁步进电动机
典型应用场景：空调风门调节，小型云台，安防监控器，智能洁具，投影仪镜头调节，发电机节气门，自动门锁
重量：55g
|
型号
|
电压
|
相数
|
相电阻
|
驱动方式
|
步距角
|
减速比
|
起动频率
|
运行转矩
|
绝缘耐压
|
绝缘等级
|
|
Model
|
Voltage
(V)DC
|
Phase
|
Resistance/phase
(Ω)
|
Drive Method
|
Step Angle
（Deg）
|
Speed Ratio
|
Pull in Rates（PPS）
|
Pull out Torque (g.cm)
|
Dielectric Stength
|
Class of insulation
|
|
35BYJ212H-10-5J
|
5
|
2
|
10
|
2-1-2 Bipolar
|
3.75/5
|
1:5
|
600
|
500
|
500V AC 1Min
|
E
|
|
35BYJ212H-30-13J
|
12
|
2
|
30
|
2-1-2 Bipolar
|
3.75/13
|
1:13
|
600
|
800
|
500V AC 1Min
|
E
|
|
35BYJ212H-20-22J
|
12
|
2
|
20
|
2-1-2 Bipolar
|
3.75/22.3
|
1:22.3
|
600
|
2000
|
500V AC 1Min
|
E
|
|
35BYJ412H-10-42J
|
5
|
4
|
10
|
4-1-2 Unipolar
|
3.75/42.5
|
1:42.5
|
600
|
2500
|
500V AC 1Min
|
E
|
|
35BYJ412H-100-64J
|
12
|
4
|
100
|
4-1-2 Unipolar
|
3.75/64
|
1:64
|
600
|
2500
|
500V AC 1Min
|
E
|
|
35BYJ26H-10-42J
|
5
|
2
|
10
|
2-1-2 Bipolar
|
7.5/42.5
|
1:42.5
|
600
|
1200
|
500V AC 1Min
|
E
|
|
35BYJ46H-100-64J
|
12
|
4
|
100
|
4-1-2 Unipolar
|
7.5/64
|
1:64
|
600
|
1800
|
500V AC 1Min
|
E
|
|
|
