35BYJ 减速永磁步进电动机
典型应用场景：空调风门调节，小型云台，安防监控器，智能洁具，投影仪镜头调节，发电机节气门，自动门锁
重量：50g
|
型号
|
电压
|
相数
|
相电阻
|
驱动方式
|
步距角
|
减速比
|
起动频率
|
运行转矩
|
绝缘耐压
|
绝缘等级
|
|
Model
|
Voltage
(V)DC
|
Phase
|
Resistance/phase
(Ω)
|
Drive Method
|
Step Angle
（Deg）
|
Speed Ratio
|
Pull in Rates（PPS）
|
Pull out Torque (g.cm)
|
Dielectric Stength
|
Class of insulation
|
|
35BYJ26-70-41J
|
12
|
2
|
70
|
2-1-2 Bipolar
|
7.5/41.6
|
1:41.6
|
500
|
2000
|
500V AC 1Min
|
E
|
|
35BYJ46-40-24J
|
12
|
4
|
40
|
4-1-2 Unipolar
|
7.5/24
|
1:24
|
500
|
1500
|
500V AC 1Min
|
E
|
|
35BYJ46-40-30J
|
12
|
4
|
40
|
4-1-2 Unipolar
|
7.5/30
|
1:30
|
500
|
2500
|
500V AC 1Min
|
E
|
|
35BYJ46-50-32J
|
12
|
4
|
50
|
4-1-2 Unipolar
|
7.5/32
|
1:32
|
500
|
2500
|
500V AC 1Min
|
E
|
|
35BYJ46-130-85J
|
12
|
4
|
130
|
4-1-2 Unipolar
|
7.5/85
|
1:85
|
500
|
1500
|
500V AC 1Min
|
E
|
|
35BYJ46-300-85J
|
24
|
4
|
300
|
4-1-2 Unipolar
|
7.5/85
|
1:85
|
500
|
1800
|
500V AC 1Min
|
E
|
|
|
