50BY 永磁步进电动机
典型应用场景：打印机，扫描仪的走纸与定位机构，智能门锁，云台，相机镜头驱动，小型阀门，流量调节，自动化仪表，小型分析仪器，精密传动装置
重量：300g
|
型号
|
电压
|
相数
|
相电阻
|
驱动方式
|
步距角
|
起动频率
|
静转矩
|
绝缘耐压
|
绝缘等级
|
|
Model
|
Voltage
(V)DC
|
Phase
|
Resistance/phase
(Ω)
|
Drive Method
|
Step Angle
（Deg）
|
Pull in Rates（PPS）
|
Holding Torque (g.cm)
|
Dielectric Stength
|
Class of insulation
|
|
50BY28L-30
|
12
|
2
|
30
|
2-2 Bipolar
|
11.25
|
240
|
580
|
500V AC 1Min
|
E
|
|
50BY48L-30
|
12
|
4
|
30
|
4-2 Unipolar
|
11.25
|
200
|
500
|
500V AC 1Min
|
E
|
|
50BY212L-30
|
12
|
2
|
30
|
2-2 Bipolar
|
7.5
|
240
|
700
|
500V AC 1Min
|
E
|
|
50BY412L-30
|
12
|
4
|
30
|
4-2 Unipolar
|
7.5
|
200
|
630
|
500V AC 1Min
|
E
|
|
50BY26L-30
|
12
|
2
|
30
|
2-2 Bipolar
|
15
|
240
|
500
|
500V AC 1Min
|
E
|
|
50BY46L-30
|
12
|
4
|
30
|
4-2 Unipolar
|
15
|
200
|
420
|
500V AC 1Min
|
E
|
|
|
