50TKYJ 减速永磁同步电动机
典型应用场景：空调风门调节，小型云台（安防监控器），智能洁具，投影仪镜头调节，发电机节气门，自动门锁
重量：200g
|
型号
|
电压
|
频率
|
相电阻
|
移相电容
|
空载电流
|
减速比
|
转速
|
运行转矩
|
绝缘耐压
|
绝缘等级
|
|
Model
|
Voltage
(V)DC
|
Frequency
(Hz)
|
Resistance/phase
(Ω)
|
Capacitor
(μF)
|
Input Current
(mA)
|
Speed Ratio
|
Speed
(RPM)
|
Pull out Torque
(g.cm)
|
Dielectric Strength
|
Class of insulation
|
|
50TKYJ24-1
|
24
|
50
|
130
|
8.2
|
185
|
1:501
|
1
|
25/37
|
500V AC 1Min
|
E
|
|
50TKYJ24-1.5
|
24
|
50
|
130
|
8.2
|
185
|
1:336
|
1.5
|
20/30
|
500V AC 1Min
|
E
|
|
50TKYJ24-2
|
24
|
50
|
130
|
8.2
|
185
|
1:247
|
2
|
16/24
|
500V AC 1Min
|
E
|
|
50TKYJ24-2.5
|
24
|
50
|
130
|
8.2
|
185
|
1:202
|
2.5
|
13/20
|
500V AC 1Min
|
E
|
|
50TKYJ24-4
|
24
|
50
|
130
|
8.2
|
185
|
1:125
|
4
|
9.5/14
|
500V AC 1Min
|
E
|
|
50TKYJ24-5
|
24
|
50
|
130
|
8.2
|
185
|
1:100
|
5
|
8/12
|
500V AC 1Min
|
E
|
|
50TKYJ24-6
|
24
|
50
|
130
|
8.2
|
185
|
1:81
|
6
|
6.5/10
|
500V AC 1Min
|
E
|
|
50TKYJ24-8
|
24
|
50
|
130
|
8.2
|
185
|
1:62
|
8
|
5.5/8.5
|
500V AC 1Min
|
E
|
|
50TKYJ24-10
|
24
|
50
|
130
|
8.2
|
185
|
1:50
|
10
|
4/7
|
500V AC 1Min
|
E
|
|
50TKYJ24-15
|
24
|
50
|
130
|
8.2
|
185
|
1:33.28
|
15
|
3.5/5
|
500V AC 1Min
|
E
|
|
50TKYJ24-20
|
24
|
50
|
130
|
8.2
|
185
|
1:25
|
20
|
4
|
500V AC 1Min
|
E
|
|
50TKYJ24-30
|
24
|
50
|
130
|
8.2
|
185
|
1:16.7
|
30
|
2.6
|
500V AC 1Min
|
E
|
|
50TKYJ24-32
|
24
|
50
|
130
|
8.2
|
185
|
1:15.6
|
32
|
2.5
|
500V AC 1Min
|
E
|
|
50TKYJ24-60
|
24
|
50
|
130
|
8.2
|
185
|
1:8.3
|
60
|
1
|
500V AC 1Min
|
E
|
|
|
